CGTech VERICUT 9.3.0 (x64)

CGTech VERICUT 9.3.0 (x64)

CGTech VERICUT 9.3.0 (x64)
x64 | Languages:Multilanguage | File Size: 4.98 GB

VERICUT is a 3D solids-based software program that interactively simulates the material removal process of an NC program. The program depicts multi-axis milling/drilling as well as multi-axis turning and combination mill/turn machining. It enables you to verify the accuracy and quality of your NC program. Inefficient motion or programming errors that could potentially ruin a part, damage the fixture, or break the cutting tool can be corrected before the program is run on an CNC machine tool.

Verification is the foundation of the VERICUT product line and is required to run any of the other add-on modules. Superior Performance: VERICUT's unique algorithm provides fast, accurate results. Performance does not degrade with increased cuts, so VERICUT can process programs with millions of cuts and virtually any type of material removal technique.

Base Verification verifies 3-axis milling and 2-axis turning (including multiple setup positions). The Multi-Axis module is required to detect collisions between the tool, stock and fixture for rotary 4 & 5-axis positioning/indexing motion. Add Multi-Axis to detect collisions during positioning and to remove material during continuous four and five axis milling, drilling, turning, and combination mill/turn operations.

Verification detects errors such as
Incorrect or misread blueprints
Inaccurate programming
Incorrect tool path motions
Rapid motion contact
Collisions with fixtures and clamps
Tool shank and holder collisions
CAD/CAM and post-processor bugs

System Requirements
OS:Windows 7 or 10 64-bit Professional
CPU:AMD Ryzen Threadripper, Intel i7 or Xeon
Memory:32 GB or higher
GPU:AMD Radeon Pro WX with 4 GB GPU RAM or higher / NVIDIA Quadro with 4 GB GPU RAM or higher
Display:1920 x 1080 (or higher) resolution, dual monitor
Storage:Solid State Drive (SSD) or NVMe drive with at least 75 GB free
